Slim power supply
Slim Switching Power Supply



Model

360W-12V

250W-12V

200W-12V

150W-12V

120W-12V

60W-12V

Size L*W*H(mm)

223*70*42

223*70*42

200*58*40

200*58*40

 190*46*36

160*40*34

Output

Start time, hold-up time(ms)

Ton≤1000ms,Td≥20ms @230Vac Full Load

Rise time(ms)

Typ:20ms @230Vac Full Load

Ripple/Noise(mVp-p)

120mVp-p

 Input

Input Voltage(V)

110VAC/264VAC

Frequency (Hz)

50Hz–60Hz

Efficiency

82%

Inrush current(A)

Cold star <20A/230VAC

Leakage current(mA)

<3mA/240VAC

 Environment

working Temperature (°C)

0°C - +40°C

Storage Temperature(°C)

-30°C - +60°C

Humidity(%)

20% - 90% RH non condensing

 Safety/ EMC

Withstand voltage(VAC)

I/P-O/P:1.5KVAC,I/P-FG:1.5KVAC,OP-FG:0.5KVAC 1min

Safety  Standard

EN/UL60950-1,GB4943

EMC  Standard

EN55022 Class B,EN61000-4-2,3,4,5,6,8,11 GB17626.5 Level3

 Protection

Over voltage Protection

>115%-135% Rated output voltage

Over load Protection

>105%-150% Auto recovery

Short circuit Protection

Latched
